canned fruit vegetable processing line,fruit canning machine

canned fruit vegetable processing line

canned fruit vegetable processing line

Description

Canned fruit vegetable processing line


It is customized line based on raw material, processing capacity and way of packing.


1.Raw mateial → 2.Core removing →3.Turnover→4.Soda water spraying→5.Peeling and washing→ 6.Pre-cooking

 → 7.Cooling → 8.Sorting → 9.Hair removing→10.Slicing →11.Fruit filling(←Botte washing←Cans unloading)

→12.Syrup filling→13.Exhauster→14.Vacuum sealing→15.Canned fruit→16.Sterilization→17.Drying

→18.Cans Palletizer→19.Storage→20.Labeling→21.Final product→22.Case packing→23.Case Palletizer→24.Shipping.



Item
Name
Product Description
2
Digging nuclear
Through the high-speed rotation twist open peach to achieve digging nuclear.
3
Turnover
Roll the peach, make it skin up one side up.
4
Soda water spraying
To the peach skin side sprinkled with soda.
5
Peeler and cleaner
Remove the peach skin and wash it.
6
Pre-cooked
Cook peaches
7
Cooling
Cool and clean peaches
8
Pick
Pick peaches, sort the size level.
9
Remove hair
Remove the hair that may fall in the fruit.
10
Slicer
Cut the peaches into strips.
11
Filling
Pour the peach into the can bottle.

Botte washing
Wash the glass can bottle.

Depalletizer
Unload the glass bottle onto the assembly line.
12
Pouring juice
Add sugar water to the cans.
13
Exhauster
Drain the inside air of the fruit in the can.
14
Sealing
Capping on the can,Sealing can.
16
Sterilization
To the canned water bath sterilization.
17
Dryer
Dry the cans outside.
18
Cans Palletizer
Palletizer fruit cans.
20
Labeler
Fruit canned Labeler.
22
Case packer
Put the fruit cans in the box.
23
Case Palletizer
The cartons are palletized.
